dB Technologies

DB Technologies DVA-T12

DB Technologies DVA-T12

Regular price $4,707.00 USD
Regular price Sale price $4,707.00 USD
Sale Sold out

The DVA T12 3-way 12" active line array speaker features state-of-the-art neodymium speakers and high-performance digital amps with total of 1,410W output power.

In combination with top-drawer DSP and premium quality AD-DA converter, it delivers high-definition sonic images with massive SPL for large sound reinforcement applications.

The global group of dBTechnologies companies develops and manufactures individual speaker components autonomously, and often specifically for the given application.

It has been DB Technologiwes long-standing policy to build from the bottom up components with specs tailored to deliver the best audio performance for the application.

DVA T12 is a step up the evolutionary ladder from the successful DVA T4 line array system. Although it provides more power and has greater range, its active three-way design makes it just as easy to set up and install as its predecessor.

Features

  • Weighing just 63lbs, this remarkably compact unit belies its unobtrusive look by enabling you to set up very powerful line arrays that deliver extraordinary performance.
  • Extended low-end performance: A 12" neodymium woofer in a band-pass housing covers the low frequency range. Remarkably powerful, it packs an assertive punch that reaches down to 60 Hz to enable full-range applications. The 12" woofer is slanted inside the housing, giving the cabinet a lean, unobtrusive look.
  • Accurate and awesomely efficient midrange response: The DVA T12's two 6.5" neodymium midrange are placed close together to maximize coherent coupling and response for those critical midrange frequencies. The speaker resides in a sealed basket to optimize the displacement volume. This makes the midrange even more responsive. With a high BL factor, it reacts far faster to transients and renders each attack with awesome accuracy. Both 6.5" midrange are equipped with an optimized phase plugand feed into a front loaded horn to achieve a uniform coverage pattern.
  • High-definition top end: The 1" neodymium HF drivers feature 1.4" Mylar diaphragms. Exceptionally light and responsive, they deliver richly detailed signals with remarkably linear frequency response. Specially developed for use in line arrays, these ultra compact drivers may be deployed in very close proximity to one another. This is essential to minimize interference insuch arrays. The DVA T12 is loaded with three HF drivers tuned specifically for the custom designed array horn. This combination maximizes the coupling of the drivers‘ outputs and extends the range of the HF signal.

Specifications

  • Acoustical data
    • Frequency Response [+/- 3dB]: 60 - 19.000 Hz
    • Max SPL: One Unit: 136 dB
    • HF: 3x1 "
    • Voice Coil HF: 1.4 "
    • Directivity: 100x10 ° Single unit
    • Horn: Integrated CD Horn
    • MF: 2x 6.5 "
    • Type MF: Neodymium Sealed Basket Phase Plug Horn Loaded
    • Voice Coil MF: 2 "
    • LF: 12 "
    • Type LF: Neodymium
    • Voice Coil LF: 3 "
  • Amplifier
    • Amp Technology: Digipro® G2
    • Amp Class: Class D
    • HF Amp: 350 W RMS
    • MF Amp: 350 W RMS
    • LF Amp: 710 W RMS
    • Cooling: Convection
  • Processor
    • Controller: DSP 56 bit
    • AD/DA Converter: 24 bit/96 kHz
    • System Presets: 8, HF/Low-mid correction
    • Limiter: Dual Active Limiter Multiband RMS, Peak, Thermal
    • Crossover Frequency MF-HF: 1800 Hz
    • Slope MF-HF: 24 dB/Octave
    • Crossover Frequency LF-MF: 420 Hz
    • Slope LF-MF: 24 dB/Octave
  • Input
    • Signal Input: 1x balanced XLR female
    • Signal Output: 1x balanced XLR male
    • Network: RDnet remote control RJ45 connector IN/OUT
    • Power Socket: 1x Powercon In 1x Powercon Out
    • Voltage Range: 90 - 240 V
  • Mechanics
    • Housing: Polypropylen PP Aluminium reinforced
    • Housing Design: Trapezoidal 10°
    • Rain Cover: Included
    • Rigging Points: Integrated rigging hardware
    • Width: 23.2"
    • Height: 15.44"
    • Depth: 17.2"
    • Weight: 63.93 lbs
Specifications
Item # DB003
MPN -
Manufacturer dB Technologies
